  • Product code: 21693
  • Jubilee
  • In Stock
£0.59 excl. VAT
£0.71inc. VAT
Banding Diameter: 9.5-12mm
Pack Size: Single
Specification Size guide

  • If you’re looking to order large quantities, call us on (0)1905 794875 for more information.

  • View the product details below to learn more about this product.


You may also need the following:


Jubilee Original Range Mild Steel Zinc Protected Hose Clip

The Original Range of Jubilee clips in Mild Steel is a firm favourite of many industries due to their cost-effective price point and excellent clamping performance. As the name suggests, these zinc-plated jubilee clips are the original version of Jubilee's worm drive hose clamp.

They are a popular choice with automotive manufacturers and especially popular with aftermarket users due to their ease of use. You can use them to secure coolant and ventilation hoses on vehicles with the safe knowledge the clamp will last at least as long as the vehicle.

Due to their cost-effective price point, the mild steel original range jubilee clip is used by the DIY industry for fastening hose pipes, drain hoses and many other applications around the home. Although it is an “entry-level” product, you should not dismiss it as only for the DIY enthusiast; you will still find these durable Original Jubilee Clips in use on construction sites and heavy machinery connecting hydraulic and pneumatic lines, giving years of dependable service.

Key Features Of The Original Range Mild Steel Jubilee Clip

  • Zinc Protected - A corrosion-resistant coating on the clamp ensures that the hose clip will withstand the test of time. The Mild steel variant has been tested to deliver the equivalent of 60 years lifespan before showing red rust when installed in a typical UK urban environment.
  • Cost Effective - One of the most competitively priced product ranges within the greater Jubilee range. The Jubilee Original range even gives the spin-offs and unbranded items a run for their money.
  • Wide Range Of Sizes - Available in sizes suitable from 9.5mm through to 318mm hoses, making them ideal for many applications.
  • Ease Of Use - Requiring no specialist tools meaning these clips can be easily used even by novices.
  • Adjustability - Each clip size has an adjustment range, making getting a consistent fit and a good-quality seal easier.
  • Reusability - Once removed, you can use these clips again without diminishing their performance, saving you money in the long run.
  • Consistent Materials - To enhance the corrosion resistance of these clamps, all metals used in constructing a clamp are of the same type. This feature stops the bi-metallic corrosion that can plague inferior offerings from other brands.

Key Industries The Original Range Jubilee Clamp is used in:

Card image cap

Agricultural

Card image cap

Automotive

Card image cap

DIY

Card image cap

Industrial

Part No. BS No. Adjustment Band Width mm Band Thickness mm Recommended Torque Nm Max. Torque Nm Max. Pressure PSI
mm Inches
000MS 12 9.5- 12 ⅜ - ½ 9.9 0.762 3.4 4.5 203
M00MS 16 11- 16 ½ - ⅝ 9.9 0.762 3.4 4.5 203
00MS 20 13- 20 ½ - ¾ 9.9 0.762 3.4 4.5 203
0MS 22 16- 22 ⅝ - ⅞ 13.0 0.914 4.2 5.6 203
0XMS 25 18- 25 ¾ - 1 13.0 0.914 4.2 5.6 203
1AMS 30 22- 30 ⅞ - 1⅛ 13.0 0.914 5.1 6.8 203
1MS 35 25- 35 1 - 1⅜ 13.0 0.914 5.1 6.8 102
1XMS 40 30- 40 1⅛ - 1⅝ 13.0 0.914 5.1 6.8 102
1MMS 45 32- 45 1¼ - 1¾ 13.0 0.914 5.1 6.8 102
2AMS 50 35- 50 1⅜ - 2 13.0 0.914 5.9 7.9 102
2MS 55 40- 55 1⅝ - 2⅛ 13.0 0.914 5.9 7.9 102
2XMS 60 45- 60 1¾ - 2⅜ 13.0 0.914 5.9 7.9 102
3MS 70 55- 70 2⅛ - 2¾ 13.0 0.914 6.7 9 102
3XMS 80 60- 80 2⅜ - 3⅛ 13.0 0.914 6.7 9 44
4MS 90 70- 90 2¾ - 3½ 13.0 0.914 6.7 9 44
4XMS 100 85-100 3¼ - 4 13.0 0.914 6.7 9 44
5MS 120 90-120 3½ - 4¾ 13.0 0.914 6.7 9 44
6MS 140 110-140 4⅜ - 5½ 13.0 0.914 6.7 9 44
6XMS 150 120-150 4¾ - 5⅞ 13.0 0.914 5.9 7.9 18
7MS 165 135-165 5¼ - 6½ 13.0 0.914 5.9 7.9 18
7.5MS 190 158-190 6¼ - 7½ 13.0 0.914 5.9 7.9 18
8.5MS 216 184-216 7¼ - 8½ 13.0 0.914 5.9 7.9 18
9.5MS 242 210-242 8¼ - 9½ 13.0 0.914 5.9 7.9 18
10.5MS 267 235-267 9¼ - 10½ 13.0 0.914 5.9 7.9 18
11.5MS 292 260-292 10¼ - 11½ 13.0 0.914 5.9 7.9 18
12.5MS 318 286-318 11¼ - 12½ 13.0 0.914 5.9 7.9 18

Measuring Your Clamp

These clips are measured based on their internal diameter. To find the size of the clip, simply measure the outside diameter of the item you are clamping onto.

You should be sure to measure the outside diameter when measuring up to ensure you get the best fit possible.

Available In:

Mild Steel - 304 Stainless Steel - 316 Stainless Steel

Alternatives To This Mild Steel Original Range Jubilee Clip

  • Need Something With Greater Corrosion Resistance? - Take a look at the Jubilee Original Range 304 Grade Stainless Steel Hose Clip.
  • Looking For Something Heavier Duty? - Check out the Jubilee Zinc Protected Superclamps. These feature a broader band cross-section and a bridge that helps to distribute clamping force evenly.
  • Not sure how long a hose clip you need? - Take a look at the Jubilee Zinc Plated Multiband kits; these come complete with everything you need to make your own custom-sized worm drive screw bands.

Need Assistance Finding The Best Hose Clip For Your Needs?

Are you in need of a high-quality hose clip? Look no further than Start Safety UK. Our extensive selection of hose clips comes in various shapes and sizes, all stocked on our shelves and available for the quick delivery to your location. If you have any technical questions or inquiries about bulk orders, our knowledgeable staff can assist – just give us a call at 01905 794 875.
