Armco Barrier Enclosure Kit (Starter Kit)

Product code: 15554-YE-CZ
Start Traffic
In Stock

£613.55 excl. VAT

£736.26inc. VAT

Armco Kit End Cap: Yellow Cap

Yellow Cap
Fishtail End

Armco Leg Type: Cast In Z-Section

Cast In Z-Section
Cast In RSJ Section
Bolt Down Z-Secton
Bolt Down RSJ Section

Specification

Size guide

If you’re looking to order large quantities, call us on (0)1905 794875 for more information.
View the product details below to learn more about this product.

You may also need the following:

Armco Barrier Enclosure Kit - Starter Kit

Our Armco Enclosure kit comes with two flexible corners, six legs, two end caps and three sections of 1.6m beam as well as all required fixings. The kit includes everything needed to place a crash barrier around a vulnerable structure in a U-shape around it.

Each corner provided is our flexible fabricated type, this ensures that installations, where an obtuse angle is required, are still catered for. This kit can be purchased with either bolt down or cast in leg types to suit the installation location. End caps can also be specified as required to suit your needs, if you require a different end cap or leg than is available in this kit please do not hesitate to contact our sales team.

This Armco crash barrier kit is made from the same high-quality components that we offer for sale separately in our Armco barrier category. They are made from high-quality hot-dip galvanised steel and engineered to good tolerances making assembly on site very easy. Our Extension kit is also available allowing you to extend any edge of this installation by 1.6 metres for each kit purchased.

Key Features Of Our Armco Flexible Internal Corner Kit

Comes Complete With All Fixings - Including lap bolts, post bolts and ground anchor bolts (for kits where a bolt down Armco post has been selected).
Compatible With Our Armco Extension Kit - Allows you to easily extend one or both sides of this corner kit.
Includes High-Quality Components - As with all our Armco kits they include only the best high quality, hot dip galvanised steel components.
Makes Armco Easy - Armco installations can be difficult to get your head around but with our kits it is easy. We are also here to help if you get stuck.
Suitable For Off-Highway Use - All our Armco equipment is perfect for off-highway use in warehouses, car parks, distribution centres for providing protection against vehicular impact.

Choosing The Right Leg For Your Armco Kit

Leg Fixing Method

Cast in / Dig in - These are concreted into the ground using post-mix or a similar material. They are ideal for use when fitting the barrier into a soft substrate (such as grass) along the edge of a car park.
Bolt Down - These are great for those who want to use the barrier on hard standing such as concrete, if fitting onto tarmac you will need to cast concrete footings for the posts to be secured to. The posts are fitted by drilling holes into the surface and bolting down the barrier.

Leg Section Type

Z-Section - comes in at a lower price and offers more deflection than an RSJ beam. Is ideal for areas where there is plenty of space behind the barrier.
RSJ Section - A much stiffer heavier duty leg that deflects less, more suitable for areas where space behind the barrier is tight.

Component List

How many components you will receive in this kit and the overall footprint of the kit will depend on the options selected. Below table includes details of what is included in each individual kit.

Leg Type	End Cap Type	Fixings
Cast In	Yellow End Cap	Post Bolts - 6 Lap Bolts - 32
Cast In	Fish Tail Ends	Post Bolts - 6 Lap Bolts - 40
Bolt Down	Yellow End Cap	Post Bolts - 6 Lap Bolts - 32 Anchor Bolts - 24
Bolt Down	Fish Tail Ends	Post Bolts - 6 Lap Bolts - 40 Anchor Bolts - 24

Other Armco Kits In This Range

Armco Starter Straight Kit With Yellow Ends And Bolt Down Z Section Posts

Armco Straight Kit

This is our most basic “full” kit, it includes everything you need including ends of your choice to make a clean straight Armco barrier install.

Armco Corner Kit With External Corner, Bolt Down RSJ Posts and Fishtail Ends

Armco External Rigid Corner Kit

Our external corner kit is ideal for surrounding external building corners or machinery. Providing protection from two faces.

Armco Extension Kit

This kit can be used to extend any of our “starter” kits adding 1.6m of length to any installation.

Internal Armco Kit With RSJ Posts and Soft Yellow End Caps

Armco Internal Rigid Corner Kit

This internal kit is ideal for protecting walls from moving vehicles within warehouses and factories

Need More Information About Our Armco Safety Barrier Kits?

Speak to one of our friendly team today, they will assist you with any questions you have about our barrier systems, including our steel barriers, Armco barrier, pedestrian barriers and more. Our phone lines are open during normal office hours, with our sales team being available on 01905 794 875.
